Squeak Noise when Door Glass Moves Up or Down – 2016 Mazda MX-5

“This site contains affiliate links for which OEMDTC may be compensated”

2016 MX-5 – SQUEAK NOISE WHEN DOOR GLASS MOVES UP AND/OR DOWN

APPLICABLE MODEL(S)/VINS

2016 MX-5 vehicles with VINs lower than JM1ND******112654 (produced before February 29, 2016)



Squeak noise when the door glass moves up and/or down. This concern happens especially when the door glass is wet with moisture or after a car wash.



door glass

This is caused by stick-slip noise occurring at the contact surfaces between the door glass and the weather strip. With repeated moving up and down, the anti-noise paint on the weather strip peels off.

To prevent the stick-slip noise, a high slide-ability tape has been added to the weather strip.



REPAIR PROCEDURE

  1. Remove the door trim according to the instructions on MS3 online or the Workshop Manual.
  2. Replace the weatherstrip on both doors with modified ones.
  3. Install the door trim.



PART(S) INFORMATION

Part Number Description Qty. Notes
N2Y0-58-760 Weatherstrip (R), Door 1 Right side
N2Y0-59-760 Weatherstrip (L), Door 1 Left side
