2017 Mazda3, 2017 Mazda6 – Forward Sensing Camera (FSC) Aiming Procedure Change
The Forward Sensing Camera (FSC) Aiming procedure has changed for the 2017 Mazda3 and 2017 Mazda6. The new aiming procedure can be performed dynamically or statically.
Dynamic Aiming
MNAO recommends performing the dynamic aiming procedure because of its simplicity.
Note: If the dynamic aiming (mid-driving aiming) procedure cannot be performed (due to bad weather, darkness, etc.), perform the static aiming (stationary aiming) procedure.
Static Aiming Changes (table below shows a few examples of the changes)
Previous Static Aiming | New Static Aiming | |
| Number of Paper Target Sheets | 2 | 12 |
| Paper Target Height | 7.9 in (20 cm) | 10.86 in (27.6 cm) |
| Paper Target Width | 12.4 in (31.5cm) | 47.55 in (120.7 cm) |
| Paper Target center height from ground | 50 in (127 cm) | 55.1 in (140 cm) |
Always refer to the Workshop Manual when performing FSC aiming. The aiming procedure may change at any time and vary by model.
