NHTSA ID Number: 10162018
Manufacturer Communication Number: 09-025-19-3607
Summary
Some vehicles may exhibit a condition where the front seat cushion trim comes off the seat frame at the front end. This may be found on vehicles with all types of the seat trims (leather, leatherette and fabric). The front seat cushion is attached to the seat frame using folding collars.This is caused by the collars slipping out of the seat frame when an excessive force is applied to the seat cushion.
5 Affected Products
Vehicle
MAKE | MODEL | YEAR |
MAZDA | MAZDA3 | 2014-2018 |
APPLICABLE MODEL(S)/VINS
2014-2018 Mazda3 (Mexico built) with VINS starting with 3MZ
DESCRIPTION
Some vehicles may exhibit a condition where the front seat cushion trim comes off the seat frame at the front end. This may be found on vehicles with all types of the seat trims (leather, leatherette and fabric). The front seat cushion is attached to the seat frame using folding collars.
NOTE: Sample images in this TSB are a Mazda2, but they are applicable to Mazda3.
This is caused by the collars slipping out of the seat frame when an excessive force is applied to the seat cushion.
Customers having this concern should have their vehicle repaired using the following repair procedure.
REPAIR PROCEDURE
1. Verify concern.
2. Attach strips of double-sided tape to the folding collars (hooks) to increase the grasping force by filling the gap.
NOTE: The double-sided tape is not intended to adhere to the seat cushion frame.
a. Lock the seat at the rear most position.
b. Clean the small folding collars (1) with a clean shop towel and isopropyl alcohol.
c. Cut the tape into two 42 mm x 20 mm strips and attach them to the small folding collars as shown.
NOTE: Using a ruler (or equivalent tool), press fit the tape for best adhesion. DO NOT remove the protective foil from the tape.
d. Move the folding collars (hooks) in the order of arrows (1) and (2) shown in the figure and install the front seat cushion trim to the front seat cushion frame.
NOTE: First engage the large center folding collar and then the side small folding collars. DO NOT remove the protective foil from the tape and pull the folding collar.
3. Press down on the area (1) three times by hand to verify that the folding collars do not come off.
PARTS INFORMATION
Scotch (R) Outdoor Mounting Tape 4011-SP
NOTE: Obtain procured tape locally. If the specified tape is not available, one of the following tapes is recommended.
- 1.0 mm thick high density foam backing
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
https://www.nhtsa.gov/recalls?nhtsaId=10162018
https://static.nhtsa.gov/odi/tsbs/2019/MC-10162018-0001.pdf
- 3-pack of double stick tape rolls with dispensers; permanent adhesive on both front and back provides reliable, inconspicuous bonding
- Narrow width for precise results
- Double-sided design offers a no-mess alternative to gluing for light-duty attaching and mounting tasks
- This tape comes on a handheld dispenser for quick and portable use
- Great alternative for home use, school presentations, art projects, and more
- 【Multifunctional EZlifego Nano-tech Tape】- By using the most advanced nano-technology, made of the latest acrylic gel material, our heavy duty two sided adhesive tape has incredibly strong adhesion and excellent durability. The perfect solution to all your DIY mounting project.
- 【Easy to Use】- No Tools Required. Powerful 2-Way Bond capability makes objects firmly attached to any contact surface. Instant Bonding does not require curing or drying stage. It can be easily cut to any size or length you need, all you need to do is stick the tape to the surface of the item.
- 【Removable & Traceless & Weatherproof】- The reusable transparent two sided sticky tack tape leaves no glue residue, easy to remove and will not damage surfaces. This industrial strength super strong adhesive tape works perfectly on almost any smooth surface indoors or outdoors, such as wall, tile, glass, plastic, metal, marble, ceramic, etc.
- 【Diversified Uses to Meet All Your Needs】- Strong Holding Power can perfectly mount or repair stuff without drilling hole or nails, fixing or pasting items such as picture hangers, frames, photos, festival decorations, wall paper stickers, posters, hooks, floating shelves, desk holders, carpets, power sockets, art crafts, board shelf, LED, DIY items, school & house room decor aesthetic and so on.
- 【EZlifego Tape Is an Essential for Daily Life】- Join the 3 million+ powered by our leading technology, it will bring great convenience to your life! Using Tips: Be slow and careful during the removal step, our adhesive tape has strong viscosity, which may cause the wall surface to peel off during removal due the unstable nature of the painted wall.
- Smooth or Rough Surfaces: Double sided tape instantly and easily fastens to both rough and smooth surfaces alike; perfect for your next DIY wall mounting project
- Super Strong: Where typical fasteners won’t work, this strong, double sided wall tape can hold up to 38 lbs, keeping objects firmly attached to any surface
- Permanent, Two-Way Bond: The heavy duty adhesive mounting tape bonds to smooth or rough surfaces in just 60 seconds, including glass, plastic, metal, & more
- Weatherproof: Industrial strength, heavy duty double sided tape clearly adheres and permanently bonds objects to almost any indoor or outdoor surfaces
- Crystal Clear: This permanently clear double sided adhesive tape won't yellow over time, making it the perfect clear tape to cleanly finish your DIY project
- DOUBLE SIDED TAPE FOR ARTS AND CRAFTS: 6 rolls of Scotch Double Sided Tape, each with a Tape Dispenser, offers a neat, clean, strong and long-lasting way to hold art and crafts projects together, making it a great addition to your crafting supplies
- MESS-FREE BONDING ADHESIVE: Both sides of the tape are coated with permanent adhesive for a strong, secure hold without the drips, clogs and air bubbles similar to white glue
- INVISIBLE TAPE: This double-sided clear tape holds things together without being seen, making it a less messy alternative to glue for school, art and office supplies
- TAPE WITH NO LINING, HAS PROTECTIVE WRAP: While the tape does not have a peel away liner, unlike scrapbook tape, there is an 8" protective liner that needs to be removed before tape can start dispensing
- IDEAL FOR SCHOOL, ART AND OFFICE SUPPLIES: Perfect for creating scrapbooks, cardmaking, paper crafts, gift wrapping, home decor projects, collages, holding work documents together, mixed media art and party decorations
- Size: 1/24" x 1/2" x 10' [1mm (Thickness) x 1.3cm (Width) x 3m (Length)]; Total Quantity: 1
- Strong Adhesion: This transparent foam tape is made of the latest material: gel-acrylic, the adhesion is 3 times of the regular adhesive tape
- User-friendly: Adopted the nano-micro-molecular technology, our mounting tape is removable, residue-free, reuseable after washing, recyclable
- Damage-free: Compared to traditional fixing methods screw, nail, it will not damage your attached objects. Leave no trace after removal
- Multipurpose: It can be used in home, office, car for wall hanging, applicance fixing, wall panel and carpet installation
- DOUBLE SIDED TAPE FOR ARTS AND CRAFTS: 2 rolls of Scotch Double Sided Tape, each with a Tape Dispenser, offers a neat, clean, strong and long-lasting way to hold art and crafts projects together, making it a great addition to your crafting supplies
- MESS-FREE BONDING ADHESIVE: Both sides of the tape are coated with permanent adhesive for a strong, secure hold without the drips, clogs and air bubbles similar to white glue
- INVISIBLE TAPE: This double-sided clear tape holds things together without being seen, making it a less messy alternative to glue for school, art and office supplies
- TAPE WITH NO LINING, HAS PROTECTIVE WRAP: While the tape does not have a peel away liner, unlike scrapbook tape, there is an 8" protective liner that needs to be removed before tape can start dispensing
- IDEAL FOR SCHOOL, ART AND OFFICE SUPPLIES: Perfect for creating scrapbooks, cardmaking, paper crafts, gift wrapping, home decor projects, collages, holding work documents together, mixed media art and party decorations
- 【Strong Adhesion】: Our heavy duty double sided tape is made of premium acrylic gel via advanced nano tech with great holding power. Getting your mounting activities done fast and securely without drilling and nails, a must have for dorm room essentials.
- 【Removable and No Residue】: Our removable double sided tape heavy duty leaves no sticky residue and won't damage most surfaces upon removal such as glass, metal, plastic, marble, wood. No need to clean the mess like other kind of adhesive, totally renter friendly.
- 【Weatherproof】:Our heavy duty adhesive double sided tape with high temperature and solvent resistance will stick to almost any smooth surfaces and works perfectly indoor and outdoor. It's perfect for mounting or repairing items such as pictures hanging strips, frames, festival decorations, LED plates, nameplates, posters, hooks, shelves, phone holders, carpets, flowerpots, power sockets, DIY items, home & office decor and so on. Perfect for classroom, college dorm room decor.
- 【Easy Storage and Dirt-free】: With our innovative protective PC holder, our strong viscosity double-sided tape won't stick to any other things when lying down, making it easier for storage. It can be easily cut to any size and mounted on wall for convenient hanging.
- 【Caution to Use】: Please be cautious when using the tape on painted wall due to strong adhesion and the nature of painted wall, which may peel off painted wall upon removal. Please keep the mounting surface dry, clean and free of oil when mounting to make instant and permanent bond and get great water and moisture resistance ability. Applying the tape vertically on the items can make stronger bonds.
- Smooth & Fast Rolling: The double sided adhesive tape rollers are equipped with micro axles that bring a smooth, fast and easy application. The tape roller glides effortlessly and is reliably free from jamming. It rolls on easily either straight or curved. Suitable for both children and adults.
- Mess-Free Clean Finish: Unlike traditional glue or glue sticks that take time on waiting, the double sided tape dispenser needs no drying time and no wrinkling, which offers a mess-free adhesion experience without destroying your materials
- Photo Safe & Permanent Adhesion: Since being acid-free and archival safe, these adhesive tape runners are photo-safe and ideal for storing your favorite photos in a scrapbook for decades without ruining. The tape runner has really good permanent adhesion. Compact and handy to be taken anywhere you go.
- Good Assistant for Crafts Projects: Besides being helpful in scrapbooking, these double sided tape dispenser rollers are also ideal for arts and crafts projects, making collages, mounting recipes, sealing envelopes, gift wrapping, and many other applications. Great for home, office and school projects.
- Valued Pack of 6: You are getting total of 6 packs double-sided adhesive permanent tape runner in different vibrant colors. Each roll holds 0.3-inch by 315 inch double sided tape, and 157.5 feet length in total.
- IDEAL FOR PAINTED DRYWALL: One of the most commonly used surfaces
- STRONG BOND: Delivers a strong, permanent bond on contact
- HOLDS UP TO 15 LB: Features 3M industrial strength adhesive. To hold 1 lb use 3 inches, To hold 15 lb use 45 inches
- SURFACES: Designed for Painted Drywall, Finished Wood, Metal, Acrylic, Tile and Glass
- INDOOR USE: Application temperature 50°F to 100°F
- Package Included: You will receive two rolls of clear double sided tapes, a total length of 400 inches. Two widths (0.5 inches and 1 inch) can meet your different pasting needs, making it perfect for your next DIY wall-hanging project
- Strong Adhesion: Whether you are using it outdoors or indoors, our strong nano tape can provide long-lasting and reliable fixation. But for temporary pasting or hanging heavy objects, we do not recommend using it on wallpaper and painted walls
- Instant Hold: Our heavy duty double sided tape provides a fast and safe solution to mount. It can be easily bonded in just 60 seconds without nails and hammers. Children can also easily complete lightweight wall-hanging projects
- Residue Free: Unlike other poster tapes, our double sided mounting tape does not leave adhesive residue after removal from a smooth surface. It is the perfect solution for renters, students, and anyone who wants to avoid damaging furniture
- Versatile Uses: Our two sided tape is a must-have for families, cars, apartments, classrooms, and offices. You can hang photo frames, mirrors, murals, posters, LED lights, holiday decorations, and other home decorations wherever you need them
Last update on 2024-04-16 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Technical
Service Bulletin Mazda North American Operations
Irvine, CA 92618-2922
Page 1 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
Subject:
Bulletin No.: 09-025/19
FRONT SEAT CUSHION TRIM COMING OFF SEAT FRAME
Last Issued: 06/17/2019
BULLETIN NOTES
This bulletin supersedes the previously issued bulletin(s) listed below. The changes are noted in Red.
Previously issued TSBs:
Date issued:
09-044/18
12/18/18
APPLICABLE MODEL(S)/VINS 2014-2018 Mazda3 (Mexico built) with VINS starting with 3MZ
DESCRIPTION
Some vehicles may exhibit a condition where the front seat cushion trim comes off the seat frame at the front end. This may be found on vehicles with all types of the seat trims (leather, leatherette and fabric). The front seat cushion is attached to the seat frame using folding collars. NOTE: Sample images in this TSB are a Mazda2, but they are applicable to Mazda3.
This is caused by the collars slipping out of the seat frame when an excessive force is applied to the seat cushion. Customers having this concern should have their vehicle repaired using the following repair procedure.
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
Page 2 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
REPAIR PROCEDURE
1. Verify concern.
2. Attach strips of double-sided tape to the folding collars (hooks) to increase the grasping force by filling the gap.
Cross section of the seat cushion frame
Hook
Front seat cushion frame
Front cushion trim
Tape
NOTE: The double-sided tape is not intended to adhere to the seat cushion frame.
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
Page 3 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
.
a. Lock the seat at the rear most position.
b. Clean the small folding collars (1) with a clean shop towel and isopropyl alcohol.
c. Cut the tape into two 42 mm x 20 mm strips and attach them to the small folding collars as shown.
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
Page 4 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
NOTE: Using a ruler (or equivalent tool), press fit the tape for best adhesion. DO NOT remove the protective foil from the tape.
d. Move the folding collars (hooks) in the order of arrows (1) and (2) shown in the figure and install the front seat cushion trim to the front seat cushion frame.
Cross section of the seat cushion frame
Hook
Front seat cushion frame
Front cushion trim
Tape
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
Page 5 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
NOTE: First engage the large center folding collar and then the side small folding collars. DO NOT remove the protective foil from the tape and pull the folding collar.
3. Press down on the area (1) three times by hand to verify that the folding collars do not come off.
PARTS INFORMATION
Parts Number
Description
Qty.
Notes
N/A
Tape
1
Scotch (R) Outdoor Mounting Tape 4011-SP. One roll of tape will repair 7 vehicles.
NOTE: Obtain procured tape locally. If the specified tape is not available, one of the following tapes is recommended.
Heavy duty double sided tape
1.0 mm thick high density foam backing
Bulletin No.: 09-025/19
Last Issued: 06/17/2019
Page 6 of 6
CONSUMER NOTICE: The information and instructions in this bulletin are intended for use by skilled technicians. Mazda technicians utilize the proper tools/
equipment and take training to correctly and safely maintain Mazda vehicles. These instructions should not be performed by “do-it-yourselfers.” Customers
should not assume this bulletin applies to their vehicle or that their vehicle will develop the described concern. To determine if the information applies,
customers should contact their nearest authorized Mazda dealership. Mazda North American Operations reserves the right to alter the specifications and
contents of this bulletin without obligation or advance notice. All rights reserved. No part of this bulletin may be reproduced in any form or by any means,
electronic or mechanical—including photocopying and recording and the use of any kind of information storage and retrieval system —without permission in
writing.
© 2019 Mazda North American Operations, U.S.A.
WARRANTY INFORMATION
NOTE:
This warranty information applies only to verified customer complaints on vehicles eligible for warranty repair.
This repair will be covered under Mazda’s New Vehicle Limited Warranty term.
Additional diagnostic time cannot be claimed for this repair.
Warranty Type
A
Symptom Code
89
Damage Code
97
Part Number Main Cause
****-88-111 or ****-88-161 (Select the part number of seat cushion trim applicable to the subject vehicle from the GEPC and enter it.)
Quantity
0
Operation Number / Labor Hours:
XXP7PBRX / 0.3 Hrs. (Both sides)
NOTE: Claim the locally procured tape with the sublet code “H9” for the first repair only.
