4721B – Tire Air Valve May Leak – 2021 Mazda CX-30 & Mazda3

February 22, 2021 NHTSA CAMPAIGN NUMBER: 21V101000

Tire Air Valve May Leak

A sudden air leak from the tire air valve may cause a loss of vehicle control while driving, increasing the risk of a crash.



NHTSA Campaign Number: 21V101

Manufacturer Mazda North American Operations

Components TIRES

Potential Number of Units Affected 599



Summary

Mazda North American Operations (Mazda) is recalling certain 2021 Mazda3 and CX-30 vehicles. Air may suddenly leak from the tire air valve.



Remedy

Mazda will notify owners, and dealers will replace all four tire air valves with new parts, free of charge. The recall began April 6, 2021. Owners may contact Mazda customer service at 1-800-222-5500 Option 4. Mazda’s number for this recall is 4721B.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Mazda has a Recall




REPAIR PROCEDURE
Recall Campaign 4721B

Safety Recall 4 7 21 B 2021 Mazda3 & CX-30 Air May Leak Suddenly from Tire Valve Stem



A. VEHICLE INSPECTION PROCEDURE

Verify that the vehicle is within the following ranges:



CAUTION: THIS PROCEDURE IS INTERIM AS PARTS ARE NOT YET AVAILABLE TO REPLACE

Models Subject VIN range Subject production date range
2021MY     CX-30 3MVDM**** MM-217514- 229817 From September 25, 2020 through November 9, 2020
2021MY Mazda3 3MZBP**** MM 207935 – 207975 From October 22, 2020 through October 23, 2020



The asterisk symbol “*” can be any letter or number.



Repair Flow Chart



Affected recall campaign 4721B

Replace all Wheel Units for all wheels with new Unit.

Perform WHEEL UN IT REGISTRATION.

Repair complete





Warning:   Damage to the Tire, Valve Stem or Wheel Rim due to improper installation will not be reimbursed by the warranty department. Please follow all warnings when replacing the Tire Valve Stems.



B: REPAIR PROCEDURE

1. Remove in the order indicated in the table.



# Description Note
1 Valve cap N/A
2 Tire N/A
3 Wheel unit component Tire Valve Stem (TPMS Unit)



2. Remove the Tire – CAUTION: Do not damage the Wheel.

3. Remove the Tire Valve Stem (TPMS Unit) using a T-10 TORX Bit

4. Pull down the Wheel unit from valve stem. If needed use a standard TPMS Service Tool (available locally) and place a soft, scratch-resistant cloth on the wheel rim to prevent scratching/damage.

5. Remove the valve stem using a soft, scratch-free material between the tool and the wheel to prevent scratching/ damage.

6. Install Tire Valve Stem (TPMS Unit) – Quantity 4 – in the reverse order of removal.

7. Remove the valve cap.

8. Install the Wheel unit component to the valve stem. Flat side of the sensor must be facing the wheel.



Caution: DO NOT separate the valve and sensor unit. If removed, a new complete assembly will be needed (cannot claim under the recall)



9. Install the Tire Valve Stems (Quantity= 4). If needed use a standard TPMS Service Tool and place a soft, scratch-resistant cloth on the wheel rim.

10. Verify the installation by checking the Distance between the Valve stem base and ensure there is no Gap where the Tire Valve Stem attaches to the wheel Groove and

11. Re-install the tire to the rim. Refer to the Workshop manual for Tire Installation note if needed.

Caution: To avoid damage of Wheel unit component, refer the Workshop manual as necessary.



12. Re-fill the tire with air and install the tire valve stem cap



CAUTION

  • A direct TPMS wheel unit has an exclusive valve cap. Always install the direct TPMS exclusive valve cap.
  • The wheel unit air pressure stem is made of aluminum and can be damaged. Do not tilt or use excessive side force when checking the air pressure or filling a tire with air. Some tire pressure gauges and air filling nozzles have extended tips, which could bend or break the air pressure stem of the wheel unit due to the added force they can apply.
  • Do not use a tire pressure gauge with an extended tip or air injector nozzle, because it will apply excessive force to the air pressure stem of the wheel unit.



WHEEL UNIT ID REGISTRATION

Note: After the wheel unit replacement, registration of the wheel unit identification codes must be performed. Please follow the steps below to perform the wheel unit registration.

Register the Wheel Unit ID according to the instructions on MGSS online: WHEEL UNIT ID REGISTRATION



1. Switch the ignition ON (engine off or on).

2. Switch the ignition off. Note: The TPMS warning light will illuminate and flash – this is normal until programming is complete.

3. Leave the vehicle with the ignition switched off for a minimum of 19 minutes.

4. Switch the ignition on and start the engine.

5. Drive the vehicle at a minimum speed of 16 mph (25 km/h) or more for a minimum of 3 minutes.

6. After driving for 3 minutes, verify that the TPMS warning light does not flash and is not illuminated.

7. Leave engine idling for an additional 5 minutes to prevent the low battery risk warning lamp from displaying on the IC cluster.



C. CAMPAIGN LABEL INSTALLATION:



1. Fill out a blue “Campaign Label” (9999-95-065A-06) with Campaign No: “4721B”, your dealer code, today’s date.



2. Affix it to the hood or bulkhead as shown:



3. Return the vehicle to customer.



END OF REPAIR PROCEDURE




PARTS AND WARRANTY INFORMATION
Recall Campaign 4721B



CONDITION OF CONCERN

On certain subject vehicles, the wheel and tire assembly may be equipped with a tire air valve having damage to the air valve sealing surface. If the affected tire air valve is installed, it is possible that an inflated tire may result in either a slow or sudden loss of air. A sudden air leak from the tire air valve may cause a loss of vehicle control while driving, increasing the risk of a crash.

A warning lamp and warning messages in the Multi-Information Display may notify the driver of a reduction in tire pressure if this defect occurs.



Causal factor:

Certain previously-installed and removed tire air valves might be mixed with new parts at the supplier due to improper isolation procedure. The previously-installed and removed tire air valve may have a damage on the sealing surface.



OUTLINE OF REPAIR

The tire air valves on all four wheel and tire assemblies will be replaced with new ones. Please refer to the Repair Procedure document on MGSS for further details.



SUBJECT VEHICLES

Model Subject VIN range Subject production date range
CX-30

built at MMVO

3MVDM**** MM 217514- 229817 From September 25, 2020 through November 9, 2020
Mazda3

built at MMVO

3MZBP**** MM 207935 – 207975 From October 22, 2020 and October 23, 2020



The asterisk symbol “*” can be any letter or number.



OWNER NOTIFICATION

Mazda will notify U.S. owners by first class mail no later than XXXX xx, 2021 .



PARTS INFORMATION

Description Part Number Quantity Note
Wheel Sensor

(Tire air valve with TPMS)

BDGF-37-140 4
Campaign Label 9999-9 5-065A-06 1=50

labels

Obtain in Mazda e-Store

(no charge)



WARRANTY CLAIM PROCESSING INFORMATION

Replacement of Tire Air Valves
Process Number AM009A
Symptom Code 99
Damage Code 99
Causal Part Number BDGF-37-140
Quantity 4 pcs.
Labor Operation XXT23XRX
Labor Hours 1.3 hrs.



Note: If the replacement of tire air valves is outsourced, please submit the actual cost incurred with the Sublet code “Z9”.



RENTAL CAR INFORMATION

Mazda recommends the usage of the MCVP loaner vehicle when available. If all MCVP loaner vehicles are in use and unavailable, and the customer needs a rental car, then use your  local rental facility and offer a rental car. Be sure that every effort is made to repair the car within one business day or less, so the next customer can receive the same experience.



Rental Car Warranty Claim Information

MCVP Vehicle Preferred Rental Agency Vehicle
Warranty Type Code N/A

MCVP does not require claim submission

A
Symptom Code 99
Damage Code 99
Part Number Main Cause 5555-47-21 BR
Part Quantity 0
Labor Ooeration Code MM024XRX
Labor Hours 0
Sublet – Rental Car
Sublet Invoice

Number

Number from Rental Invoice

or Dealer Purchase Order

Sublet Type Code Enter “Z9” (other)
Sublet Amount Up to $30.00 per day for the number of days customer had rental car
Sublet Text Number of days rental car was supplied to customer



Rental expenses exceeding the two-day limit will require prior Warranty Department Authorization, as outlined in the Mazda Rental Car Reimbursement Program policy.









2 Affected Products

Vehicles

MAKE MODEL YEAR
MAZDA CX-30 2021
MAZDA MAZDA3 2021




10 Associated Documents

Miscellaneous Document – PARTS AND WARRANTY INFORMATION Recall Campaign 4721B

RMISC-21V101-4989.pdf 676.488KB

RMISC-21V101-4989




Recall Quarterly Report #1, 2021-2

RCLQRT-21V101-5297.PDF 211.138KB

RCLQRT-21V101-5297




Defect Notice 573 Report

RCLRPT-21V101-6905.pdf 219.066KB

RCLRPT-21V101-6905




Recall Acknowledgement

RCAK-21V101-8809.pdf 783.442KB

RCAK-21V101-8809




Manufacturer Notices(to Dealers,etc)- Subject: Notification of Safety Recall 4721B – 2021 CX-30 & 2021 Mazda3 vehicles Air May Leak Suddenly from Tire Valve Stem (TPMS unit)

RCMN-21V101-2947.pdf 172.997KB

RCMN-21V101-2947




ISSUED Owner Notification Letter(Part 577)- Spanish Version

RCONL-21V101-2439.pdf 375.992KB

RCONL-21V101-2439




ISSUED Owner Notification Letter(Part 577)

RCONL-21V101-7773.pdf 681.392KB

RCONL-21V101-7773




Manufacturer Notices(to Dealers,etc)- Dealer Letter

RCMN-21V101-8598.pdf 524.303KB

RCMN-21V101-8598




Remedy Instructions and TSB

RCRIT-21V101-6282.pdf 914.628KB

RCRIT-21V101-6282




Recall Quarterly Report #3, 2021-4

RCLQRT-21V101-1698.PDF 211.316KB

RCLQRT-21V101-1698
