2013-2015 CX-5 – FRONT SEAT BACK POCKET TORN
APPLICABLE MODEL(S)/VINS
2013-2015 CX-5
When folding the rear seat back forward, the head restraint (B) may catch on the front seat back pocket (A). If weight is applied to the rear seat at this time (i.e. passenger pushes on rear seat, etc.), the front seat back pocket may become torn.
REPAIR PROCEDURE
- Replace the affected front seat back trim (s) with a modified one according to MS3 online or the Workshop Manual (section 09-13).
PART(S) INFORMATION
Part Number | Description | Qty | Notes | |
New | Old | |||
KFY8-88-131 | KF39-88-131A-34 | Seat Back Trim (R) | 1 | STE, STD-LEATHER (Mexico) |
KD51-88-131A-34 | 1 | STD-LEATHER (North America) | ||
KFY7-88-131 | KF39-88-131A-02 | 1 | STE, STD-LEATHER (Mexico) | |
KD51-88-131A-02 | 1 | STD-LEATHER (North America) | ||
KFY6-88-131 | KD49-88-131A-34 | 1 | STB, STC-CLOTH B (North America) | |
KF37-88-131A-34 | 1 | STB-CLOTH B (Mexico) | ||
KFY5-88-131 | KD49-88-131A-02 | 1 | STB, STC-CLOTH B (North America) | |
KF37-88-131A-02 | 1 | STB-CLOTH B (Mexico) | ||
KFY4-88-131 | KF33-88-131A-34 | 1 | STA-CLOTH A (Mexico) | |
KD45-88-131A-34 | 1 | STA-CLOTH A (North America) | ||
KFY3-88-131 | KF33-88-131A-02 | 1 | STA-CLOTH A (Mexico) | |
KD45-88-131A-02 | 1 | STA-CLOTH A (North America) | ||
KFY8-88-181 | KF39-88-181A-34 | Seat Back Trim (L) | 1 | STE, STD-LEATHER (Mexico) |
KD51-88-181A-34 | 1 | STD-LEATHER (North America) | ||
KFY7-88-181 | KF39-88-181A-02 | 1 | STE, STD-LEATHER (Mexico) | |
KD51-88-181A-02 | 1 | STD-LEATHER (North America) | ||
KFY6-88-181 | KD49-88-181A-34 | 1 | STB, STC-CLOTH B (North America) | |
KF69-88-181A-34 | 1 | STB-CLOTH B (Mexico) | ||
KFY5-88-181 | KD49-88-181A-02 | 1 | STB, STC-CLOTH B (North America) | |
KF69-88-181A-02 | 1 | STB-CLOTH B (Mexico) | ||
KFY4-88-181 | KF33-88-181A-34 | 1 | STA-CLOTH A (Mexico) | |
KD45-88-181A-34 | 1 | STA-CLOTH A (North America) | ||
KFY3-88-181 | KF33-88-181A-02 | 1 | STA-CLOTH A (Mexico) | |
KD45-88-181A-02 | 1 | STA-CLOTH A (North America) |
NOTE: Confirm the part number(s) in the parts catalog for the subject VIN and place an order for the corresponding modified service part(s).
