Poor Cowl Grille Appearance – 2016 Mazda CX-3

“This site contains affiliate links for which OEMDTC may be compensated”

2016 CX-3COWL GRILLE POOR APPEARANCE

APPLICABLE MODEL(S)/VINS

2016 CX-3 vehicles with VINs lower than JM1 DK ****** 120952 (produced before November 18, 2015)



Poor appearances at the cowl grille.



The bottom of the window shield is visible when the cowl grille is pushed.

Cowl Grille

Cowl Grille

OK Poor Appearance



The side cover of the cowl grille is deformed.

side cover of the cowl grille

side cover of the cowl grille

OK Poor Appearance



REPAIR PROCEDURE

  1. Replace both side cowl grilles. Refer to MS3 online or Workshop Manual (section 09-16).



PART(S) INFORMATION

Part Number Description Qty.
DB2W-50-7R0B GRILLE ASSY-COWL,RH 1
DB2W-50-7S0B GRILLE ASSY-COWL,LH 1
