Cracks Around Edge of Active Driving Display – 2015-2016 Mazda

“This site contains affiliate links for which OEMDTC may be compensated”
Subject:

CRACKS AROUND EDGE OF ACTIVE DRIVING DISPLAY (LOOKS FUZZY)

Bulletin No: 09-020/16
Last Issued: 03/29/2016



BULLETIN NOTE

This bulletin supersedes the previously issued bulletin(s) listed below: The changes are noted in Red beside the change bars.

Previously issued TSBs:Date issued:
09-037/1509/22/2015



APPLICABLE MODEL(S)/VINS

2016 Mazda2 Mexico built vehicles with VINs between 3MD DJ ****** 101111 to 103355 (produced from April 23, 2015 to September 29, 2015)

2015 Mazda3 Mexico built vehicles with VINs between 3MZ BM ****** 213930 to 260783 (produced from April 23, 2015 to September 29, 2015)

2015 Mazda3 Japan built vehicles with VINs between JM1 BM ****** 259983 to 275744 (produced from February 7, 2015 to May 27, 2015)

2016 Mazda6 vehicles with VINs lower than JM1 GJ ****** 411770 to 434008 (produced from February 7, 2015 to May 27, 2015)

2016 CX-3 vehicles with VINs lower than JM1 DK ****** 100037 to 103523 (produced from February 7, 2015 to May 27, 2015)





DESCRIPTION

Some vehicles may experience a fuzzy appearance (tiny cracks) around the edge of the Active Driving Display.

Cracks Around Edge of Active Driving Display - 2015-2016 Mazda | 3079a

Customers having this concern should have their vehicle repaired using the following repair procedure.



REPAIR PROCEDURE

  1. Verify customer concern.
  2. Replace the Active Driving Display. Refer to MS3 online or Workshop Manual section 09-22:
    • Mazda2 – ACTIVE DRIVING DISPLAY REMOVAL/INSTALLATION
    • Mazda3 – ACTIVE DRIVING DISPLAY REMOVAL/INSTALLATION
    • Mazda6 – ACTIVE DRIVING DISPLAY REMOVAL/INSTALLATION
    • CX-3 – ACTIVE DRIVING DISPLAY REMOVAL/INSTALLATION
  3. Verify repair.



PART(S) INFORMATION

DescriptionQty.NotesPart Number
Multi-Meter Lens1Active Driving DisplayBHR1-55-459



WARRANTY INFORMATION

NOTE:

  • This warranty information applies only to verified customer complaints on vehicles eligible for warranty repair.
  • This repair will be covered under MazdaeBay’s New Vehicle Limited Warranty term.
  • Additional diagnostic time cannot be claimed for this repair.
Mazda2, Mazda6, CX-3Mazda3
Warranty TypeAA
Symptom Code8888
Damage Code9F9F
Part Number Main CauseBHR1-55-459BHR1-55-459
Quantity11
Operation Number / Labor Hours:XXL6RXRX / 0.3 Hrs.XXL6RXRX / 0.4 Hrs.




09-020/16
